Manufacturing factory supply 1phase 3.7kw 16A portable ev charger with type 2/type 1/GBT
3.7kw portable ev charger for electric vehicle car portable charging station, type 2 portable ev charger with home use plug
Specification
| Item |
Datasheeet |
|
|
| Type |
|
PEVC1L-16A |
PEVC1L-16A-1 |
|
Input |
Power Supply |
1P+N+PE |
1P+N+PE |
|
|
Rated Voltage |
AC220～240V |
AC220～240V |
|
|
Rated Current |
16A（13A,10Aadjustable) |
16A（13A,10Aadjustable) |
|
Output |
Output Voltage |
AC220～240V |
AC220～240V |
|
|
Maximum Current |
16A（13A,10Aadjustable) |
16A（13A,10Aadjustable) |
|
|
Rated Power |
3.7KW(MAX) |
3.7KW(MAX) |
|
User interface |
Input Cable |
Cable +plug |
Cable +plug |
|
|
Cable Length |
0.5M |
0.5M |
|
|
Charger Connecter |
Cable +Type1 /Type 2/GBT Connector |
Cable +Type1 /Type 2/GBT Connector |
|
|
Cable Length |
5M |
5M |
|
|
Material |
ABS +PC |
ABS +PC |
|
|
Colour |
White + Black |
White + Black |
|
|
Three Clour LED |
● |
● |
|
|
LCD |
● |
● |
|
|
Start Mode |
|
|
|
|
Plug in and charge |
● |
● |
|
|
Tuya App |
Optional |
Optional |
|
Safety |
Ingress Protection |
Outshell IP65; Connector IP54 |
Outshell IP65; Connector IP54 |
|
|
Impact Protection |
/ |
/ |
|
|
Over Current Protection |
● |
● |
|
|
Residual Current Protection (AC30mA) |
● |
|
|
|
Residual Current Protection (AC30mA,DC6mA) |
/ |
● |
|
|
Ground Protection |
● |
● |
|
|
Surge Protection |
● |
● |
|
|
Over/Under Voltage Protection |
● |
● |
|
|
Over temperature |
● |
● |
|
|
Certification |
CE／UKCA |
CE／UKCA |
|
|
Certification Standard |
EN 61851/EN 62196 |
EN 61851/EN 62196 |
|
Enviroment |
Installation |
Portable |
Portable |
|
|
Work Temperature |
‘-25℃~50℃ |
‘-25℃~50℃ |
|
|
Work Humidity |
3%~95% |
3%~95% |
|
|
Work Altitude |
<2000m |
<2000m |
Application
Electric vehicle carusing portable charging station ev charger
Functions
LCD display&Current adjustable button&Schedule a countdown charge time&Working status indicator
Various optional plugs and type 1/type 2 connector
Over current protection&Over voltage protection&Over heating protection
Usage scenarios
Inspection
Customer Feedback
FAQ：
1.Are you manufacturing factory?---Yes, we’re XingBang Group who have three manufacturing factories and also have relevant factory certificates.
2.Can I get one sample for testing?---Yes, we can provide sample to you for testing. Sample fee will charge double fee, but the extra cost will return when first bulk order.
3.Can you print my logo on ev charger?---Yes, we can do oem according to your requirements for bulk order.
4.What’s your MOQ?---100pcs
5.Could you give solution for my project?---Yes, we have professional technical team and developping team, we will provide one-way solution to you.
6.How long delivery time: first order need about 45days after received deposite and next orders will be about 30days.
7.Does ev charger has O-PEN protection system.---We can add this function if you required.
8.Does ev charger has the RCD protection?---AC30mA+DC6mA
